# Formula for OEE calculation – problems, fixes

## Formula for OEE calculation – diagnosing problems and fixing them

The formula for OEE is simple, but the ingredients that go into the calculation for OEE decide whether you get a proper number.

Availability = (Running time / Available time)
Performance = (Real production / Theoretical production)
Quality = (Good products / Real production)

### Formula for OEE = A x P x Q

Availability is a measure of how much time the machine was made available for production, after downtime losses like machine breakdown, setup change, no raw material, etc.
Performance is a measure of the quantity that has been produced compared to what could have been produced.
Quality is a measure of rejections.

### Checklist for parameters in formula for OEE

Before doing the calculation for OEE for any time period, ensure that all these have been considered properly:

In Availability
From Available time, exclude any time in which you have decided beforehand that it must not run:
– Weekly off days
– Holidays
– Lunch break
– Tea break
– Downtime for preventive maintenance.
– Downtime for autonomous maintenance.
– Downtime for machine cleaning in every shift
– Downtime for daily scheduled meeting when the machine is stopped.

In Running time
In Running time in the calculation for OEE, include only the time when the machine is actually running and producing.
Include:
– Cycle time – time between start and end of a part’s production.
Exclude any time that is a downtime, not part of the running time:
– Setup time at part change
– Inspection time
– Rework time

Theoretical production
Use the correct values of standard cycle time and standard part unload-load time, and the correct value of Running time in the formula for OEE.

Real production
Include ALL parts produced, including rejected parts.
Exclude reworked parts. i.e. count every part only once, the first time it is made. Do not count it aqain when it is reworked. Rework time is downtime.

Good production
This is the parts produced minus rejected parts.
Exclude reworked parts. i.e. count every part only once, the first time it is made.

### Action points for correct formula for OEE

1. Ensure that you assign the correct downtimes for Availability in the formula for OEE.
2. Ensure that you use the correct standard times for Performance.
3. Ensure that you use the correct good parts and total parts, and ignore rework in Quality.

Ensure that you are truthful about considering downtimes. Do not consider a downtime as a part of the process time when it is not warranted. For example, DO NOT:
1. Consider excess part load-unload time (beyond the standard time) as part of the cycle time.
2. Consider setup time as part of the operating time.

The blog post ‘OEE formula – bad idea to cook up‘ explains why you need to be truthful with the downtimes, and
